Specifikation:

Processor: Intel Core i7, dual core with 1.7 GHz, 4 MB cache
Memory: 4 GB DDR3
Intel Panther Point PCH chipset

Interfaces:

  • 2 x M12 5 pin connectors for CAN or serial ports
  • 2 x M12 8 pin X-coded connectors for 10/100/1000BaseT Ethernet
  • 2 x M8 4 pin connectors for USB
  • 1 x M12 4 pin T-coded power supply connector
  • 1 x M12 8 pin with 4 digital input/outputs
  • 1 x 15 pin DSUB VGA connector
  • SJA 1000 CAN Controller

Power Supply: Input 9..34 V DC

Physical:

  • Ambient operating temperature range from – 40 °C .. + 70 °C
  • Dimensions (w x h x d): 270 x 200 x 80 mm (not including M connector overhang)

Supported Operating Systems: WES 7, Linux, QNX; other operating systems on request, please contact your regional Janz Tec sales office.
